Foot length measuring instrument - 3D foot scanner to accurately measure foot length

In many fields such as footwear manufacturing, orthopedics, and sports science, accurate measurement of foot length is essential for shoe matching, foot health management, and customization of orthopedic equipment.

Traditional foot length measurement methods, such as ruler measurement or foot template method, have limitations such as large measurement errors and reliance on human judgment.

With the development of 3D scanning technology, 3D foot scanners have become an important tool for high-precision foot length measurement.

The device can quickly obtain 3D data of the foot, provide accurate foot length measurement results, and is used in the customization of personalized insoles, orthopedic shoes, and professional sports shoes. This article will discuss in detail the working principle, measurement advantages, and application scenarios of 3D foot scanners in foot length measurement.

1. Working principle of 3D foot scanners

3D foot scanners use optical or laser scanning technology to obtain the complete 3D shape of the foot through non-contact measurement, and accurately calculate key parameters such as foot length, foot width, and arch height. Its working principle is as follows:

(1) Optical or laser scanning technology

Scanners usually use structured light scanning (Structured Light Scanning), laser scanning (Laser Scanning) or optical photogrammetry (Photogrammetry) and other technologies.

Structured light scanning uses the grating pattern projected onto the foot and captures the grating deformation through the camera to reconstruct the three-dimensional shape; laser scanning calculates the foot surface data through laser projection and reflection; optical photogrammetry calculates based on images from multiple angles to generate a three-dimensional foot model.

(2) Three-dimensional data acquisition and reconstruction

When the user puts the foot into the scanner or stands on the scanning platform, the device will collect image data from multiple angles in a short time, and reconstruct the point cloud through computer algorithms to generate a complete three-dimensional model of the foot.

(3) Accurate foot length calculation

After the three-dimensional model is established, the system will automatically identify the position of the heel point and the longest toe (usually the big toe or the second toe), and measure the linear distance between the two, that is, the foot length. At the same time, the system can also measure the distance between different foot feature points, such as metatarsophalangeal joint width, arch height, etc., to provide rich data for shoe customization and foot health analysis.

2. Advantages of plantar 3D scanner in measuring foot length

Compared with traditional foot length measurement methods, plantar 3D scanners have significant advantages such as high accuracy, good measurement consistency, and high degree of automation:

(1) High accuracy and small error

Traditional measurement methods are greatly affected by human factors, while the accuracy of 3D scanners can usually reach sub-millimeter level, which can provide more reliable foot length measurement data and avoid human measurement errors.

(2) Non-contact measurement to avoid deformation

Traditional ruler measurement may cause foot deformation due to pressure, thereby affecting measurement accuracy. Plantar 3D scanners use non-contact scanning technology to ensure that the foot shape remains natural during the measurement process and improve the authenticity of the data.

(3) Stereoscopic data acquisition, providing multi-dimensional information

In addition to foot length, 3D scanners can also simultaneously obtain data such as foot width, arch height, and foot symmetry, providing comprehensive foot measurement results for customized insoles and orthopedic shoes.

(4) Fast measurement speed and easy operation

Modern plantar 3D scanners can usually complete data acquisition within seconds and automatically calculate key parameters such as foot length without complex operations. They are suitable for large-scale foot measurement needs, such as shoe production and medical diagnosis.

(5) Data storage and analysis

Measurement data can be stored in a database to facilitate long-term tracking of individual foot change trends. It can also be used for big data analysis to optimize footwear product design.

3. Application scenarios of plantar 3D scanners in foot length measurement

Due to its high precision and automation, plantar 3D scanners have been widely used in many fields, mainly including the following scenarios:

(1) Personalized shoe customization

High-end shoe brands and sports shoe manufacturers use plantar 3D scanners to measure the user's foot length, and combine foot width and arch data to achieve personalized shoe customization and improve shoe matching and comfort. For example, some sports brands use scanning technology to customize exclusive running shoes for users to optimize sports performance and reduce the risk of sports injuries.

(2) Orthopedic insoles and orthopedic shoe production

For patients with foot abnormalities such as flat feet, high arches, and hallux valgus, accurate foot length measurement is crucial for the design of orthopedic insoles and orthopedic shoes. 3D scanners can accurately measure foot length and combine dynamic plantar pressure analysis to provide patients with orthopedic products that meet biomechanical needs.

(3) Medical and rehabilitation fields

Plane 3D scanners can be used to evaluate foot deformities, diabetic foot and other diseases, and help doctors develop rehabilitation plans. For example, patients with diabetic foot are prone to ulcers. 3D scanning can measure changes in foot size and combine pressure data to optimize the design of rehabilitation shoes and reduce local pressure.

(4) Monitoring of children's foot development

Children's feet grow rapidly. Regularly measuring foot length helps parents choose the right shoe size and monitor whether the foot develops normally. 3D scanners can record changes in children's foot size at different stages, providing a basis for scientific shoe selection.

(5) Sports science and ergonomics research

Researchers use plantar 3D scanners to collect foot length and foot morphology data from different populations to improve shoe design, optimize sports equipment, and improve the adaptability of ergonomic products.
