Three-dimensional measurement and inspection solutions for the base of the bathroom faucet

Regarding the measurement and three-dimensional inspection of the faucet base, the traditional three-coordinate measuring equipment is one of the methods to obtain high-precision three-dimensional data, but the long measurement process and the inability to obtain data on the surface of the object. Therefore, it is impossible to make accurate measurement and three-dimensional inspection.


The problem we are facing

1. It is necessary to quickly obtain the three-dimensional data of the faucet base and measure its size

2. To perform three-dimensional inspection of the faucet base, the shape can be evaluated through three-dimensional scanning, and an intuitive full-size inspection chromatogram can be generated, design defects or manufacturing problems can be found in time, and the hole size of the product can also be determined to ensure the assembly accuracy of the product .



Three-dimensional measurement and inspection solutions for the base of the bathroom faucet

1. Surface treatment of the faucet base, using a 3D scanner to quickly obtain the 3D data of the faucet base



2. Align and compare the 3D data of the faucet base with the original design 3D data


3. Measure the specific size data of the faucet base


Advantages of 3D scanner

1. The non-contact 3D measurement method of 3D scanner is very suitable for the production and use of hardware customers

2. Measuring without deformation, suitable for measuring thin-walled and soft parts;

3. It has a strong image magnification function, and a small size measurement ability is stronger;

4. The measurement speed is fast, which greatly improves the measurement efficiency;

5. The high density of sampling points ensures high reliability of measurement.


Conclusion

Three-dimensional measurement and inspection solution for bathroom faucet bases, using a three-dimensional scanner to obtain 3D data of the bathroom faucet base. The three-dimensional data of the faucet base is aligned and compared with the original design 3D data. The specific size data of the faucet base is measured and the full size and curved surface of the bathroom faucet are detected. , Radian, etc.
