The PTS-E series adopts advanced blue light raster scanning technology, equipped with the company's independently developed control chip and high-precision industrial camera, which can meet various high-precision three-dimensional measurement needs.

Features:

▶ Non-contact blue light scanning, the light source is fine. Adapt to the measurement of soft and easily deformable objects.

▶ Large measuring depth of field: the range of depth of field is 300~500mm.

▶ Both multi-color light scanning technology, better sensitivity adaptability.

▶ Higher detail display, resolution can reach 0.03mm.

▶ Optimized processing technology for large data volume.

▶ Suitable for scanning products of different sizes ranging from a few millimeters to a few meters.

▶ The equipment is small in size, occupies a small area, and has no noise. It can be easily brought to the measurement site. The scanning equipment can be moved when scanning large and heavy objects.

▶ Equipment supporting scanning software, independent software intellectual property rights. Professional R&D team provides 24-hour machine service, which can be customized according to customer needs.

▶ The 3D scanner is easy to operate, and it can be operated proficiently without excessive training (2-3 working days).

Photographic 3D scanner-measurement principle

The 3DOE 3D measuring head is composed of two high-resolution industrial CCD cameras on the left and right and a grating projection unit. The structured light measurement method is used to project a group of grating fringes with phase information onto the surface of the measured object using the grating projection unit. The two cameras on the left and right can measure simultaneously, and combine computer vision technology, photoelectric sensor technology, image processing technology and software control technology to obtain high-density three-dimensional data on the surface of the object in a very short time. The rotating object or scanning head is used to change the scanning angle of view. Based on the automatic splicing technology of multi-view point cloud, it can complete 360° scanning of the object in all directions.

Advantages of blue light: The shorter the wavelength, the better the reflectivity, and the better the imaging effect for objects with complex textures!
